Scientists at the Technion-Israel Institute of Technology have harnessed the power of DNA to create a self-assembling nanoscale transistor, the building block of electronics. The research, published in Science, is a crucial step in the development of nanoscale devices. Erez Braun, lead scientist on the project and associate professor in the Faculty Physics at the Technion, says science has been intrigued with the idea of using biology to build electronic transistors that assemble without human manipulation. However, until now, demonstrating it in the lab has remained elusive. “This paper shows you can start with DNA proteins and molecular biology and construct an electronic device,” he said.
“Erez Braun and his colleague Uri Sivan are some of the few pioneers in this field,” said Horst Stormer, professor in Columbia University’s Departments of Physics and Applied Physics and scientific director of the Nano Science and Engineering Centers. “This is outstanding research in the area that matters most in nano technology: self-assembly.”
To get the transistors to self assemble, the Technion research team attached a carbon nanotube – known for its extraordinary electronic properties – onto a specific site on a DNA strand, and then made metal nanowires out of DNA molecules at each end of the nanotube. The device is a transistor that can be switched on and off by applying voltage to it.
Though transistors made from carbon nanotubes have already been built, they required labor-intensive fabrication. The goal is to have these nanocircuits self-assemble, enabling large-scale manufacturing of nanoscale electronics.
DNA, according to Braun, is a natural place to look for a tool to create these circuits. “But while DNA by itself is a very good self-assembling building block, it doesn’t conduct electrical current,” he noted.
To overcome these challenges, the researchers manipulated strands of DNA to add bacteria protein to a segment of the DNA. They then added certain protein molecules to the test tube, along with protein-coated carbon nanotubes. These proteins naturally bond together, causing the carbon nanotube to bind to the DNA strand at the bacteria protein.
Finally, they created tiny metal nanowires by coating DNA molecules with gold. In this step, the bacteria protein served another purpose: it prevented the metal from coating the bacteria-coated DNA segment, creating extending gold nanowires only at the ends of the DNA strand.
The goal, Braun explained, was to create a circuit. However, “at this point, the carbon nanotube is located on a segment of DNA, with metal nanowires at either end. Theoretically, one challenge here would be to encourage the nanotube to line up parallel to the DNA strand, meet the nanowires at either end, and thus make a circuit.
“There are some points where nature smiles upon you, and this was one of those points,” Braun continued. “Carbon nanotubes are naturally rigid structures, and the protein coating makes the DNA strand rigid as well. The two rigid rods will align parallel to each other, thus making an ideal DNA-nanotube construct.”
“In a nutshell, what this does is create a self-assembling carbon nanotube circuit,” he concluded.
Scientists controlled the creation of transistors by regulating voltage to the substrate. Out of 45 nanoscale devices created in three batches, almost a third emerged as self-assembled transistors.
Braun added, however, that while this research demonstrates the feasibility of harnessing biology as a framework to construct electronics, creating working electronics from self-assembling carbon nanotube transistors is still in the future.
